Technical Data

Category

LED

Series

L-Series

Model

L5-C

Optical System

Focusable Fresnel

Light Aperture / Lens Diameter in mm

137 mm

Light Aperture / Lens Diameter in inch

5.4"

Beam Angle

14° to 50° Half Peak Angle

Weight in kg net*

Manual Version: approx. 6 kg
Pole Operated Version: approx. 7 kg

Weight in kg packed*

Manual Version: approx. 9 kg
Pole Operated Version: approx. 10 kg

Weight in lbs. net*

Manual Version: approx. 13 lbs
Pole Operated Version: approx. 16 lbs

Weight in lbs. Packed*

Manual Version: approx. 19 lbs
Pole Operated Version: approx. 23 lbs

Measurements (HxWxL) incl. Pin in mm*

Manual Version: 394 x 278 x 280 mm
Pole Operated Version: 451 x 270 x 280 mm

Measurements (HxWxL) excl. Pin in mm*

Manual Version: 321 x 278 x 280 mm
Pole Operated Version: 332 x 270 x 280 mm

Measurements (HxWxL) incl. Pin in inch*

Manual Version: 15.5 x 10.9 x 11.0"
Pole Operated Version: 17.7 x 10.6 x 11.0"

Measurements (HxWxL) excl. Pin in inch*

Manual Version: 12.6 x 10.9 x 11.0"
Pole Operated Version: 13.1 x 10.6 x 11.0"

Measurements (HxWxL) Packed size in mm*

470 x 400 x 410 mm

Measurements (HxWxL) Packed size in inch*

18.5 x 15.8 x 16.1"

Handling

Adjustable Sliding Stirrup, High-Strength Tilt Lock / Pole Operation Option (Pan, Tilt and Focus)

Mounting

16 mm / 28 mm Combo Pin (Baby 5/8” / Junior 1-1/8” Combo Pin)

Tilt Angle

+/- 90°

Lamphead Voltage Input

90 - 250 V ~, 50 - 60 Hz

Power Consumption

100 W Nominal, 115 W Maximum

Power Connection

powerCON TRUE1 (Bare Ends / Schuko / Edison)

Battery Connector

4-Pin XLR Connector (Pin 1: Negative / Pin 4: Positive)

Battery DC Voltage Range

23 to 36 V DC

White Light

2,800 K to 10,000 K continuously variable correlated color temperature

Colored Light

Full RGB+W Color Gamut with Hue and Saturation Control

Color Temperature Tolerance

+/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)

Color Rendition

CRI Average > 94, TLCI Average > 90

Green-Magenta Adjustment

Continuously adjustable (Full Minusgreen to Full Plusgreen)

Dimming

0 to 100 % continuous

Control

5-Pin DMX In and Through, On-Board Controller, Mini-USB

Wireless Control

Not integrated, via SkyLink

Remote Device Management (RDM)

DMX Setup, Hour Counter and Standard RDM Commands

Software / Mini-USB Interface

DMX Setup, Fixture Status and Firmware Upgrade through PC

Housing Color

Blue/Silver, Black

Ambient Temperature Operation

-20 to +45° C (-4 to +113° F)

Protection Class / IP Rating

I / IP20

Estimated LED Lifetime (L70)

50,000 hours

Estimated Color Shift Over Lifetime (CCT)

+/- 5 %

Certifications

CE, CB, GS, cNRTLus, FCC, PSE
